Infra light Diamond EYE - Infradiamond
Infrared lights are designed for a demanding environment with IP65 outside cover. They are made of high-quality material and electronic parts which secure an extremely long life span and above-standard performance. Infrared lights are equipped with up-to-date technology Infra-diamond which shows extra light values.
| Diamond EYE | Distance of 300 m | Camera angle | Optional |
|---|---|---|---|
| Diamond EYE | Distance of 150 m | Camera angle | Optional |
| Diamond EYE | Distance of 90 m | Camera angle | Optional |
| Diamond EYE power – a power supply belonging to the infrared light | |||
Diamond EYE
- Sturdy and resistant body
- Low power demand of 50W
- Beam length of 250m 5"/90m 35"
- 48V DC supply
- smd technology
- INFRADIAMOND unique technology of a parabolic optical system
- OPEN EYE feeding and controlling logic
- IP65 outside cover
- Modification of a scattering of light
Diamond EYE power
feeding source
- Controlling logic for Diamond EYE
- POWER – regulation of light intensity
- DELAY – time delay of switching off
- TRESHOLD – light sensitivity of connection
- 230V AC supply
- IP65 outside cover
